Тип:Тип z, сформированный тип u, холод, горячекатаный
Стандарт:5523 : 2012 ДЖИС а, 5528 : 2012 ДЖИС а, 10248-1 : 1996 ЭН БС, 10248-2 : 1996 ЭН БС, АСТМ А572М/A572-12, АСТМ А6/A6M-12
Приложения:Усиление дамбы, подпорные стены, волнорезы, переборки, экологические барьерные стены, мостовые обители, подземные гаражи
Steel sheet piles are sections of sheet materials with interlocking edges that are driven into the ground to provide earth retention and excavation support. Sheet piles are commonly used for retaining walls, land reclamation, underground structures such as car parks and basements, in marine locations for riverbank protection, seawalls, cofferdams, and so on.
For most engineering projects, installing sheet piles is typically used for scaffolding or temporary excavation protection applications. These include basement and tunnel construction.
Product Name: Steel Sheet Pile,Interlocking Sheet Pile
Type: Z Type, U Type, Cold Formed, Hot Rolled
Standard: JIS A 5523 : 2012,JIS A 5528 : 2012,BS EN 10248-1 : 1996,BS EN 10248-2 : 1996,ASTM A572M/A572-12,ASTM A6/A6M-12
Applications: Levee Strengthening, Retaining Walls, Breakwaters, Bulkheads, Environmental Barrier Walls, Bridge Abutments, Underground Parking Garages
Types of Steel Sheet Piles
Z Type Sheet Piles
U Type Sheet Piles
Cold Formed Sheet Piles
Hot Rolled Sheet Piles
Advantages of Steel Pile Sheets
- A sustainable option as made of recycled steel and the piles can often be reused
- Available in numerous combinations of size and weight
- Immediate barrier to prevent soil loss and sloughing during excavation
- Permanent sheet piles are designed to provide long service life
APPLICABLE STANDARDS
Grades of steels
CHEMICAL COMPOSITION
|
Notation |
C |
Si |
Mn |
P |
S |
Cu |
|
SY 295 |
- |
- |
- |
0.04 max. |
0.04 max. |
0.25 min. |
|
SY390 |
- |
- |
- |
0.04 max. |
0.04 max. |
0.25 min. |
MECHANICAL PROPERTIES
|
Notation |
Tensile Strength N/mm2 |
Yield Point N/mm2 |
Elongation % |
|
SY 295 |
490 min. |
295 min. |
17 min. |
|
SY390 |
540 min. |
390 min. |
15 min. |
DIMENSIONAL TOLERANCES
|
Description |
Tolerance |
|
|
Width |
+ 10mm - 5mm
|
|
|
Height |
± 4% |
|
|
Thickness |
Under 10mm |
± 1.0mm |
|
10mm & over to 16mm, excl |
± 1.2mm |
|
|
16mm & over |
± 1.5mm |
|
